Surface Laptop Studio

For help diagnosing issues with your device, check out the troubleshooting page.

On December 13, 2021, iFixit and Microsoft announced a program where iFixit Pro independent repairers and Microsoft Authorized Service Providers can purchase tools for repairing select Microsoft Surface devices directly from iFixit.com.

The Surface Laptop Studio was announced on September 22, 2021 alongside the Surface Pro 8, Surface Pro 7+, Surface Go 3, and the reveal of Microsoft’s new Windows 11 operating system. The Surface Laptop Studio hit stores on October 5 and was one of the first devices to feature Windows 11 pre-installed.

The Surface Laptop Studio is the first of yet another new lineup of Microsoft devices, and showcases an entirely new form factor with a magnesium and aluminum exterior. Its defining feature is a novel dual-pivoting display that can fold the device into a tablet as well as a canvas mode.

Microsoft designed the Studio lineup with creative professionals in mind, including strong processors and a digital stylus to fully utilize creative programs.

The Surface Laptop Studio is identifiable by model number 1964. The model number is located under the display's middle hinge point. When the device is in "laptop" mode, push the top of the display away from the keyboard and rotate it back to see the model number. Refer to Microsoft’s official guide for alternative ways to identify your Surface device.

• Quad-core 11th Gen Intel^® Core™ H35 i5-11300H
• Quad-core 11th Gen Intel^® Core™ H35 i7-11370H

• Intel^® Core™ i5 models: Intel^® Iris^® X^e Graphics
• Intel^® Core™ i7 models: NVIDIA^® GeForce RTX™3050 Ti  laptop GPU with 4GB GDDR6 GPU memory

• 16GB or 32GB LPDDR4x RAM

• Screen: 14.4" PixelSense™ Flow Display
• Refresh rate: up to 120Hz
• Resolution: 2400 x 1600 (201 PPI)
• Aspect ratio: 3:2
• Contrast ratio: 1500:1
• 10-point multi-touch
• Dolby Vision^® support

• Removable SSD options: 256 GB, 512 GB, 1TB, 2TB

• 2 x USB-C® with USB 4.0/Thunderbolt™ 4
• 3.5mm headphone jack
• 1 x Surface Connect port

• Usage
  • Intel® Core™ i5: Up to 19 hours of typical device usage
  • Intel® Core™ i5: Up to 19 hours of typical device usage
• Capacity
  • Nominal (WH): 58.0
  • Min (WH): 56.3

• Integrated Surface Slim Pen 2 storage for charging

• Windows 11 Home

• Intel® Core™ i5 models 3.83 lb (1,742.9 grams)
• Intel® Core™ i7 models 4.00 lb (1,820.2 grams)

• 12.72 x 8.98 x 0.746 inches (323.28 x 228.32 x 18.94 mm)
